  No.:HAW-RC
  Item:Diamond wire for reinforced concrete cutting


Product Description

1. Application in Building Construction:

  • Cutting off building like houses, bridge, dam, big post, cement pipes.
  • Cutting underwater buildings.
  • Efficient dry cutting of reinforced concrete.
  • Cutting steel structure

2. Wire Specifications:

Item No.

Bead Diameter (mm)

Bead/meter (pcs/m)

Application

Coating

HAW-RC11040

Dia11.0

40

Reinforced Concrete

Rubber+Spring

HAW-GQ10540

Dia10.5

40






3.  Parameters:

Application
Wire Speed(m/s)
Cutting Speed (m2/h)
Life( m2 /m)
Normal Wet cutting
22-25
2.0-5.0
2.0-6.0
Dry cutting
18-22 1.0-2.5 2.0-3.0
Underwater cutting
12-15 1.0-2.0 2.0-3.0
Cutting Steel structure
12-15 0.5-1.0 0.5-1.0

4. Bead Specification:

Bead Diameter (mm)

Working Layer Length (mm)

Bead Type

Dia11.0

L6.4. L6.0

Sintered

Dia10.5

L6.4, L5.8

Sintered

Dia10.5

L6.2

Electroplated double layer diamond

5. More Images of Diamond wire for reinforced concrete cutting.




6. Advance of our diamond wire:

Produced under the most advanced automatic production line, selected Germany steel wire rope and adopted the latest production technology and unique technique, our diamond wire has the advantages as follows:
 1. Rarely breakage ratio during cutting therefore increase working lifetime.
 2. Automatic production ensures stable quality and performance.
 3. Safe,high efficiency and environment protection.
  4. We supply different diamond wire according to different usage.

Packaging & Shipping

Packaging: PVC Shrinking Belt+Master Carton
Meters/Roll: 50Meters
Shipment: By Fedex, UPS, TNT, DHL, By Air, or By Sea.

Estimated Time of Delivery: 1- 2 Weeks

Estimated Time of Arrival: 1 week by Air, 1-6 weeks by sea depends on different distance.

Our Service

1. Wire sawing operational assistance service.

2. All type of diamond wire saw are offered.
3. Other specifications are available upon request.
